Depth Tracker: Option for 28XX
The Depth Tracker is a fully integrated electronics module that adds depth tracking capability to the Laversab 28xx Series rig-floor computers. The module includes all the necessary safety barriers that allow the user to place the encoder, hook load sensor and manual slip switch in ‘hazardous’ locations. A user-friendly Depth Tracker Software is included, which allows the user to configure and calibrate the depth tracker module. If an EDR or other data logger is not available, the Depth Tracker Software can also be used for logging all the depth tracker measurements for the entire job duration.
- Specifications
- Documents
System Configuration
Product Type:
Depth Tracker add-on for Laversab platform
Certifications:
ATEX / IECEx Zone 2 (System) & Zone 1 (Sensors)
Sensor I/O:
1x Encoder, 1x Hook-load,
1x Slips, 3x 4-20mA spare channels
RS232:
Ex nA nC
RS422 / 485:
Ex nA nC
Encoder Interface:
Ex ib
Hook-load Interface:
Ex ib
Manual Slip Switch Interface:
Ex ib
Spare 4-20mA channels:
Ex ib
Sensors (Optional)
Encoder:
Hohner & Dynapar supported; others optional
Hook-load:
Advanced Sensor Design & Hohner Supported; others optional
Slips Switch:
Digital Sensor OR auto-detect
Cables:
Length: 1ft - 250ft options
Quality: Hard Usasge
Application software
Pre-loaded Software:
Laversab LINKS DT
Data formats:
WITS0 / WITSML / Custom Formats
Reporting:
Depth vs MWD & LWD
Gamma Logging
Resistivity Logging
Relogging functionality
