  • Avionics Radio Test Set: ARTS-7000

    The Laversab ARTS-7000 is a multifunction all-in-one Avionics Radio Test System – ARTS. It is designed to meet all aircraft radio test requirements in a single unit. The ARTS-7000 is controlled wirelessly – whether from inside the cockpit or around the aircraft. It is controlled via a simple yet intuitive touch-screen interface. The ARTS-7000 is built to reduce upfront costs, simplify aircraft testing, and cover both current & future radio test requirements.

    Standard tests: Radio Communication, Navigation, Distance Measuring Equipment, Mode S, ADSB, Emergency Location Transmitters

    Optional tests: TCAS, UAT, GPS

    The ARTS-7000 is user configurable and expandable to meet future avionics requirements. It is built to test any airborne platform, including General aviation, Commercial airliners, helicopters, and military applications.

  • Model 6300-M3: Military Pitot Static Tester

    NSN: 4920 01 569 1292

    The 6300-M3 Automated Tester is designed to connect directly to a Military aircraft’s Pitot and Static system. Using the small and light-weight Remote unit a user can operate the tester from the cockpit and use it to test the entire pitot and static system of the aircraft, including altimeters, climb indicators, airspeed / Mach indicators, air data computers, and auto-pilots. The tester includes built-in vacuum and pressure pumps and emergency manual bleed-down valves. The operator simply connects power, and the pitot and static hoses, to make the unit operational. The high accuracy of this unit meets the latest RVSM requirements. Also, it needs to be calibrated only once a year. The use of “Profiles” makes it possible for the operator to run through a test using only a single key on the Remote unit. The wide operating temp. makes it ideal for military applications.

  • Model 6300-M4: High-range Pitot Static Tester

    The 6300-M4 Automated Tester is designed to connect directly to a military aircraft’s Pitot and Static system. Using the small and light-weight Remote unit a user can operate the tester from the cockpit and use it to test altimeters, climb indicators, airspeed / Mach indicators, air data computers, and auto-pilots. The tester includes built-in vacuum and pressure pumps and emergency manual bleed-down valves. The operator simply connects power, and the pitot and static hoses, to make the unit operational. The high accuracy of this unit meets the latest RVSM requirements. Also, it needs to be calibrated only once a year. The use of “Profiles” makes it possible for the operator to run through a test using only a single key on the Remote unit. The high altitude and airspeed range of this tester make it ideal for use on fighter/attack aircraft.

  • Model 6300L: Automated Pitot Static Tester

    NSN: 6625 01 358 6854

    Last time buy for this product is June 30, 2021.
    For new requirements, we recommend Model 6300 or Model 6200

    The 6300L RVSM Automated Tester is designed to connect directly to an aircraft’s Pitot and Static system. Using the small and light-weight Remote unit a user can operate the tester from the cockpit and use it to test the entire pitot and static system of the aircraft, including altimeters, climb indicators, airspeed / Mach indicators, air data computers, and auto-pilots. The tester includes built-in vacuum and pressure pumps and emergency manual bleed-down valves. The operator simply connects power, and the pitot and static hoses, to make the unit operational. Also, it needs to be calibrated only once a year. The use of “Profiles” makes it possible for the operator to run through a test using only a single key on the Remote unit. Also, all commands can be performed through the RS232 interface.

  • Model 6600-M4: Military Pitot Static Tester with 3 Outputs

    The 6600-M4 Automated Tester is ideal for use on military aircraft with SmartProbes™ capable of measuring AOA using Air Data. The tester has one Static output (Ps1), one Pitot output (Pt) and a third output (Ps2) which can be used to simulate either AOA or AOS. Using the small and light-weight Remote unit a user can operate the tester from the cockpit and test the entire pitot and static system of the aircraft. The tester includes built-in vacuum and pressure pumps and emergency manual bleed-down valves. The high accuracy of this unit meets all RVSM requirements. Also, it requires no maintenance other than to be calibrated only once a year. The use of “Profiles” makes it possible for the operator to run through a test using only a single key on the Remote unit.

  • Model 6500/6500-HA: Automated Air Data Test Set

    NSN: 4920 01 375 7472 (Model 6500)

    The 6500 & 6500-HA (High-Accuracy) Air Data Test Sets require only a pressure source and a vacuum source and are extremely simple to use. They can be used to test and calibrate altimeters, airspeed / Mach indicators, Climb indicators, Flight data recorders, Air data computers, and EPR indicators. The high accuracy of these units meets all RVSM requirements. Also, they need to be calibrated only once a year. The use of “Profiles” makes it possible for the operator to run through a test using only a single key on the front panel keypad of these units.

  • Model 6580/6580-HA: Automated Air Data Test Set

    NSN: 4920 01 611 1045 (Model 6580-HA)

    The 6580 & 6580-HA (High-Accuracy) Air Data Test Sets are rack-mount units with built-in pressure and vacuum pumps featuring quiet operation. These test sets can be used to test and calibrate altimeters, airspeed / Mach indicators, Climb indicators, Flight data recorders, Air data computers, and EPR indicators. The high accuracy of these units meets all RVSM requirements. Also, they need to be calibrated only once a year. The use of “Profiles” makes it possible for the operator to run through a test using only a single key on the front panel keypad of these units.
    The 6580-M1 has a built-in output switching module (OSM) with 3 Static Ports and 3 Pitot Ports on the rear panel, which can individually be controlled (opened and closed) using external inputs.

  • Hose Kit 2 (Test)

    For connecting Models 6150, 6200, 6300 (all models) to aircraft with relatively small airframes.
    For connecting Models 6150, 6200, 6300 (all models) to aircraft with relatively large airframes.
    For connecting Models 6600, 6600-M4H (without using OSM) to aircraft with “Smart Probes”.

    $50.00$100.00
  • Hose Kits

    For connecting Models 6150, 6200, 6300 (all models) to aircraft with relatively small airframes.
    For connecting Models 6150, 6200, 6300 (all models) to aircraft with relatively large airframes.
    For connecting Models 6600, 6600-M4H (without using OSM) to aircraft with “Smart Probes”.

  • MOB

    MOB (Multi Output Box)

  • UPSA Kit

    The UPSA (Universal Pitot Static Adapter) is the perfect accessory to any avionics shop. This premier system was designed exclusively for performing pitot / static system tests to most any aircraft. The UPSA can be used with or without electrical power, in the hanger or out in the field, it has you covered, which makes the system more versatile than the competition. It comes standard in dual configuration, however can be used on dual or single static port configured aircraft. The fully articulating legs allow for flexible “Static” installations & the pure gum rubber ensures a tight “Pitot” seal every time. The UPSA will give you audible as well as visual warnings in the event of a power loss or of a low vacuum situation regardless of the power configuration you’re in. The USPA is the next generation of universal adapters.

  • Aircraft Adapters

    We can provide adapters for any type of aircraft, helicopter or UAV.

    Please contact us with the details of your aircraft.
